Controller
LXV-3ACC
3ACC Constant Current Controller
1.Stable output current, good linearity. 2.RS232 serial communication. 3.LAN ethernet communication.
| Product | Model | One way output current | Total output power | One way Max. output power | Number of channels | Extenal trigger voltage |
|---|---|---|---|---|---|---|
| Spot light controller | LXV-3ACC350-2C | 0-350mA | 2W | 1W | 2 | 5-24V |
| LXV-3ACC350-4C | 0-350mA | 4W | 1W | 4 | - | - |
| LXV-3ACC700-2C | 0-700mA | 4W | 2W | 2 | - | - |
| LXV-3ACC700-4C | 0-700mA | 8W | 2W | 4 | - | - |
| LXV-3ACC1000-2C | 0-1000mA | 6W | 3W | 2 | - | - |
| LXV-3ACC1000-4C | 0-1000mA | 12W | 3W | 4 | - | - |
| LXV-3ACC1500-2C | 0-1500mA | 10W | 5W | 2 | - | - |
| LXV-3ACC1500-4C | 0-1500mA | 20W | 5W | 2 | - | - |
| LXV-3ACC2500-2C | 0-2500mA | 20W | 10W | 2 | - | - |
| Structure light controller | LXV-3ACC12400-2 | 0-400mA | 10W | 5W | 2 | - |
| LXV-3ACC12700-1 | 0-700mA | 8.5W | 8.5W | 1 | - | - |
IMAGING COMPARISON
Application Effect Analysis
Real-world inspection imaging comparison — demonstrating the contrast and uniformity advantages of LXV-3ACC.
OPTICAL DESIGN & NAMING
Optical Diagram & Model Naming Convention
Model Naming Convention
